Edge Computing Panel PCs with Intel Core Ultra Processors

Avalue Technology has released two fanless industrial panel PCs, the APC-2146 and APC-2346, powered by the Intel Core Ultra 5 125U processor platform. These 21.5-inch and 23.8-inch Full HD systems integrate neural processing unit (NPU) capabilities to support artificial intelligence (AI) edge inference. The architecture is engineered for deployment in smart retail, self-service kiosks, medical environments, and industrial automation facilities where localized data processing and human-machine interaction are required.

Edge Inference and Processing Architecture
The computing foundation of the APC series utilizes the Meteor Lake architecture of the Intel Core Ultra 5 125U processor. This platform integrates a dedicated NPU designed to offload AI workloads from the CPU, optimizing energy efficiency during intelligent image recognition and real-time data processing tasks. The hardware supports up to 32GB of DDR5 memory operating at 5600MHz, providing the bandwidth necessary for high-speed edge computing. An M.2 Key E expansion slot is available for integrating Wi-Fi and Bluetooth modules to facilitate wireless IoT connectivity. The systems are compatible with Windows 10, Windows 11, and Linux operating systems to ensure integration with existing industrial software ecosystems.

Environmental Protection and Physical Specifications
Designed for operational stability in demanding environments, the systems employ a fully enclosed fanless thermal management architecture. This design prevents dust ingress and reduces mechanical failure points, enabling continuous operation in high-dust industrial settings or sterile healthcare environments. The enclosures utilize a plastic chassis with dimensional profiles measuring approximately 45.5 mm in depth for the 21.5-inch APC-2146 and 49.5 mm for the 23.8-inch APC-2346. Both models feature projected capacitive (PCAP) multi-touch interfaces integrated into a true-flat narrow bezel display. The front panels are IP65-rated, ensuring resistance to water and dust, which facilitates routine cleaning and equipment maintenance.

Interface Connectivity and Application Contexts
The panel PCs incorporate extensive industrial I/O interfaces to support peripheral integration. Available connections include dual Intel Gigabit Ethernet ports, four USB 3.0 ports, one USB Type-C port, HDMI, and analog audio inputs/outputs. The systems operate on a 12 to 24V DC wide-range power input, accommodating variable industrial power supplies. Supporting VESA mounting standards, the hardware can be integrated into factory control machinery, digital signage enclosures, or mobile medical carts.

In retail and self-service sectors, the hardware provides the localized processing power required for backend data synchronization and high-speed network communication. Within Industry 4.0 applications, the systems function as human-machine interfaces (HMI) for real-time production monitoring, equipment integration, and quality control. For healthcare infrastructure, the fanless operation and IP65-rated screens address clinical requirements for low acoustic noise and stringent infection control protocols at nursing stations and patient bedsides.

Additional Context: This section details technical specifications and competitive benchmarking not included in the original product announcement.
The integration of Intel Core Ultra (Meteor Lake) processors in industrial panel PCs represents a shift toward local AI processing without dedicated discrete GPUs. Comparable industrial PCs have historically relied on standard Intel Core or Atom processors paired with separate AI accelerator cards. The Avalue APC-2146 and APC-2346 leverage the embedded NPU within the Intel Core Ultra 5 125U to achieve localized edge AI capabilities within a unified, fanless thermal envelope. The 15W base power of the 125U processor enables passive cooling, positioning these panels against other ruggedized HMI terminals that require active cooling to maintain high-performance inference operations.

Edited by an industrial journalist, Lekshman Ramdas, with AI assistance.

www.avalue.com
